RCS Roof Rainwater Drainage Pipes/Fittings

RCS Roof Rainwater Drainage Pipes/Fittings
Execution Standard: Refer to 《15S412: Installation of Roof Rainwater Drainage Piping》
Material: Primarily high-strength plastic
Diameter Range: Typical size/specification: Common specification is rectangular 85×65 (mm)
Application: Used to collect roof rainwater and discharge it to the ground through the system, protecting building exterior walls and foundations.
Features: Sturdy and steady form, with a hollow base structure for enhanced durability and long-lasting color retention
Customization Supported.
Log in to download file

Description

1.Product Introduction

Our PVC-U roof rainwater drainage system is a high-performance plastic piping system specifically designed for the efficient and safe discharge of roof rainwater in modern buildings. It is primarily made from unplasticized polyvinyl chloride (PVC-U), manufactured through special formulations and advanced processes, offering excellent weather resistance, impact resistance, and smooth drainage performance. This system provides a complete solution, including roof rainwater outlets, drainage pipes, fittings, and fixing brackets. The products strictly comply with relevant national standards and are committed to addressing extreme weather challenges, ensuring rapid and smooth rainwater discharge away from buildings, effectively protecting roofs, exterior walls, and foundations, and extending the overall service life of structures.

Regarding inquiries about “RCS” piping in some markets, we hereby clarify: Current national standards and mainstream engineering practices primarily specify materials such as PVC-U and HDPE for roof rainwater pipes. Our system, centered on high-performance PVC-U, delivers equivalent or even superior reliability and assurance.

Product Specifications

2.Technical Parameters

Nominal Outer Diameter

dn75, dn110, dn160, dn200, dn250, dndn31etc.

Ring Stiffness Class

SN4 and above classes

Execution Standard

GB/T 5836.1-2018， CJ/T 250-2018

Density

1350-1550 kg/m³

Longitudinal Reversion Rate

≤5%

Drop Hammer Impact Test (0°C)

TIR ≤ 10%

Weather Resistance Performance

P(Xenon lamp irradiation) test, the material resists UV, suitable for long-term outdoor exposure environments.

Fluid Performance

Coefficient of friction (approx. 0.009)

3.Connection Methods

  • Socket Fusion with Adhesive: This is the most common and economical connection method. Apply specialized PVC-U adhesive evenly to the pipe spigot and fitting socket before joining, then allow it to cure. The principle involves the adhesive dissolving the plastic at the contact surfaces, enabling molecular chain fusion to create a secure, leak-proof monolithic joint. It is suitable for most indoor drainage pipelines and non-buried outdoor drainage lines.
  • Elastomeric Seal Ring Socket Connection:For sections subject to significant temperature variations, potential minor displacement, or where easy disassembly for maintenance is desired, connections using fittings with elastomeric seal rings (typically made of EPDM) are recommended. This method allows for certain axial displacement and deflection angles, offers excellent seismic resistance, and enables quick installation. It is particularly suitable for externally mounted rainwater downpipes on high-rise buildings.

4.Key Advantages & Selling Points

  • Excellent Weather and Impact Resistance:The formulation incorporates UV inhibitors and high-efficiency impact modifiers, enabling long-term resistance to sun exposure, rain, and high-low temperature cycles. It maintains flexibility even in harsh cold climates, preventing brittleness and cracking, thereby ensuring all-weather reliable system operation.
  • High Drainage Efficiency and Clog Resistance:The pipe interior wall is extremely smooth with minimal frictional resistance, accelerating rainwater discharge. A unique hydraulic radius design optimizes full-pipe flow conditions. Coupled with large-diameter series options, it can easily handle heavy rainfall intensity, effectively reducing the risk of water ponding on roofs.
  • Superior Corrosion Resistance and Long Service Life:It exhibits strong resistance to acid rain and atmospheric chemicals, and will never rust or corrode. The system is designed with a service life exceeding 50 years, significantly reducing maintenance costs over the building’s entire lifecycle.
  • Lightweight yet High Strength, Easy Installation:Weighing only about 1/6 of traditional cast iron pipes, it saves effort in handling and construction. Flexible connection methods (adhesive or seal ring) enable fast installation and lower overall project costs.
  • Complete, Safe, and Aesthetically Pleasing System:Provides a full set of compatible accessories including rainwater outlets, access ports, vent caps, and fixing clamps. The scientifically designed system ensures smooth drainage, effectively prevents roof leakage, and allows for customizable external wall colors to harmonize with building facades.

5.Product Applications

  • Civilian and Commercial Buildings:Rainwater downpipes and horizontal discharge pipes for flat or sloped roofs of residences, villas, office buildings, shopping malls, hotels, etc.
  • Public and Industrial Buildings:Rainwater drainage systems for large-scale structures such as schools, stadiums, airports, railway stations, and factory buildings.
  • Specialized Buildings:Suitable for coastal buildings with specific requirements for corrosion resistance and wind load resistance.

6.Testing & Certifications

  • Full Compliance with National Standards:Products undergo comprehensive type testing in accordance with standards such as GB/T 5836 and GB/T 18252, including tests for longitudinal reversion, Vicat softening temperature, drop hammer impact, ring stiffness, ring flexibility, dichloromethane immersion, and more.
  • Weathering and Aging Tests:Product samples pass accelerated artificial climate aging tests of ≥1000 hours, verifying their UV resistance and long-term weathering performance for outdoor use.
  • System Hydraulic Testing:Laboratory simulations of varying rainfall intensities test the drainage capacity and venting performance of the complete piping system, ensuring scientifically reliable design.
  • Environmental and Safety Certifications:Materials comply with environmental requirements, and relevant hygiene and safety test reports can be provided.

7.Manufacturing Process Flow

  • Material Formulation and Mixing: PVC resin, stabilizers, impact modifiers (e.g., CPE), processing aids, titanium dioxide (for UV resistance), and fillers are precisely weighed according to the formula and fed into a high-speed hot mixer. They are uniformly blended at a set temperature before being transferred to a cold mixer and cooled to room temperature, resulting in a dry blend.
  • Extrusion Molding:The dry blend is fed into a conical twin-screw extruder. Under precisely controlled, segmented temperature profiles, the material is plasticized, melted, and homogenized. It is then extruded through an annular die to form the pipe parison.
  • Vacuum Calibration and Spray Cooling:The pipe parison immediately enters a vacuum calibration tank where its outer diameter and roundness are precisely set. It then proceeds to a staged spray cooling trough for gradual and uniform cooling. This process eliminates internal stresses and ensures dimensional accuracy and optimal physical properties.
  • Haul-off and Marking:A caterpillar haul-off unit provides smooth and constant pulling force. Simultaneously, permanent markings such as brand, specifications, production date, and execution standards are printed online onto the pipe surface.
  • Cut-to-Length and Inspection:Controlled by a length measuring device, the pipe is cut to precise, predetermined lengths using a planetary cutter, which produces no chips. Every pipe undergoes strict visual and dimensional inspection. Additionally, samples are taken from each production batch for key physical and mechanical performance testing.

8.Packaging and Delivery

  • Professional Protective Packaging:Pipes are packaged in bundled or crisscross frame configurations based on their specifications. Large-diameter pipes (e.g., DN200 and above) are typically secured with crisscross frames to prevent deformation during transport, while smaller-diameter pipes are usually bundled with straps and protected with plastic film. All pipe ends are fitted with protective caps. Fittings are packaged separately in cartons or woven bags with clear labeling.
  • Efficient Logistics and Delivery Support:We maintain a stable logistics partnership network and can flexibly arrange land or sea transportation. For large-scale projects, we support phased delivery plans aligned with construction schedules and provide professional unloading guidance to ensure safe arrival of goods at the construction site.

9.Sales Service

  • Pre-Sales:Complimentary technical consultations, system design recommendations, flow calculations, and product selection guidance.
  • In-Sales:Provision of detailed technical installation specification guides, and upon request, dispatch of engineers for on-site technical briefings to guide installation teams in standardized construction.
  • After-Sales:
  1. Warranty Period:Product quality assurance compliant with national regulations.
  2. Rapid Response Mechanism:Dedicated service hotline and online support platform; solution proposals provided within 24 hours for customer feedback.
  3. Spare Parts Supply Commitment: Commitment to long-term, stable supply of complete system accessories, supporting maintenance and expansion needs for decades to come.

10.Company Strengths

  • Specialization in Building Drainage:With years of deep expertise in building water supply and drainage pipeline systems, we thoroughly understand the technical challenges and engineering requirements of roof rainwater drainage. Our product solutions are derived from extensive practical experience.
  • Technical and Formulation Expertise:We operate an independent material R&D laboratory. Targeting the core requirements of weather resistance and impact resistance for rainwater pipes, we have developed proprietary modified formulations to ensure outstanding product performance in harsh environments.
  • Complete System Integration Capability:We are not only pipe manufacturers but also system solution providers. From roof rainwater outlets to underground discharge pipes, we offer a full range of seamlessly compatible products, ensuring optimized hydraulic performance of the entire system.
  • Strong Engineering Service Capability: We have cultivated a technical support team composed of seasoned engineers capable of providing end-to-end, in-depth services for large and complex projects—from initial design coordination and mid-construction guidance to final commissioning—serving as a reliable technical backbone for our clients.
